Which assembly diagrams exist for KAMAZ-53215?
KAMAZ-53215 has 235 assembly diagrams in the OEM catalogue, grouped below by vehicle system.
Engine
29| Drawing | Assembly | Parts |
|---|---|---|
| 14243 | 14243Engine | 25 |
| 14244 | 14244Engine | 49 |
| 14251 | 14251 | 44 |
| 14252 | 14252Cylinder block assembly | 32 |
| 14253 | 14253 | 21 |
| 14254 | 14254Valve timing mechanism | 12 |
| 14255 | 14255Cylinder head | 36 |
| 14256 | 14256Piston with connecting rod and rings | 20 |
| 14257 | 14257 | 14 |
| 14258 | 14258Crankshaft and flywheel installation | 21 |
| 14259 | 14259 | 6 |
| 14260 | 14260Camshaft | 9 |
| 14261 | 14261 | 4 |
| 14266 | 14266Engine crankcase ventilation | 14 |
| 14268 | 14268 | 18 |
| 14277 | 14277Engine fuel system | 62 |
| 14278 | 14278Engine fuel system | 9 |
| 14290 | 14290Installation of solenoid valve | 25 |
| 14305 | 14305 | 11 |
| 14327 | 14327Gearbox housing with shafts | 79 |
| 14338 | 14338Air distributor | 14 |
| 14339 | 14339 | 23 |
| 14340 | 14340Pressure reducing valve | 15 |
| 14352 | 14352 | 10 |
| 14361 | 14361 | 10 |
| 14409 | 14409Power steering control valve | 18 |
| 14428 | 14428 | 15 |
| 14435 | 14435Relay valve assy | 29 |
| 14437 | 14437Test port valve | 13 |
Cooling system
7| Drawing | Assembly | Parts |
|---|---|---|
| 14311 | 14311Installation of radiator and radiator seals | 17 |
| 14312 | 14312 | 6 |
| 14314 | 14314 | 23 |
| 14315 | 14315 | 21 |
| 14317 | 14317Fan drive fluid coupling | 36 |
| 14413 | 14413Power steering pipelines and oil cooler | 9 |
| 14480 | 14480 | 17 |
Fuel system
17| Drawing | Assembly | Parts |
|---|---|---|
| 14269 | 14269High-pressure fuel pump installation and drive | 28 |
| 14270 | 14270Injection pump drive shaft | 8 |
| 14271 | 14271Installation of fuel tank, coarse fuel filter and fuel lines | 23 |
| 14272 | 14272Installation of fuel tank, coarse fuel filter and fuel lines | 22 |
| 14273 | 14273Coarse fuel filter assembly | 12 |
| 14274 | 14274Fine fuel filter | 19 |
| 14279 | 14279Low-pressure fuel pump | 17 |
| 14283 | 14283High-pressure fuel pump | 27 |
| 14284 | 14284Fuel pump housing assembly | 32 |
| 14285 | 14285 | 43 |
| 14286 | 14286Fuel pump section | 20 |
| 14287 | 14287Injector | 18 |
| 14289 | 14289 | 18 |
| 14294 | 14294Pre-start heater fuel pump | 22 |
| 14298 | 14298Pre-heater fuel tank mounting | 15 |
| 14430 | 14430Fuel shut-off pneumatic cylinder | 18 |
| 14488 | 14488 | 34 |
Transmission
39Suspension & frame
12| Drawing | Assembly | Parts |
|---|---|---|
| 14381 | 14381Frame, assembly | 20 |
| 14384 | 14384Front suspension assembly | 2 |
| 14385 | 14385Front leaf spring | 23 |
| 14386 | 14386Front suspension | 39 |
| 14387 | 14387Front suspension assembly | 43 |
| 14388 | 14388Rear suspension assembly | 58 |
| 14389 | 14389Spring shoe with bushings and oil seal | 7 |
| 14392 | 14392Rear leaf spring assembly | 20 |
| 14393 | 14393Rear leaf spring assembly | 22 |
| 14447 | 14447 | 4 |
| 14473 | 14473Cab rear suspension | 19 |
| 14504 | 14504 | 36 |
Brake system
17| Drawing | Assembly | Parts |
|---|---|---|
| 14306 | 14306Installation of turbocharger | 32 |
| 14416 | 14416Rear service brakes | 31 |
| 14417 | 14417Front service brakes | 34 |
| 14419 | 14419 | 14 |
| 14420 | 14420 | 29 |
| 14421 | 14421Installation of pneumatic brakes | 18 |
| 14422 | 14422Installation of pneumatic brakes | 14 |
| 14423 | 14423Air brake compressor | 34 |
| 14424 | 14424Compressor installation | 19 |
| 14425 | 14425Air brake reservoirs | 16 |
| 14426 | 14426 | 62 |
| 14427 | 14427Dual-section brake valve with pedal | 10 |
| 14429 | 14429Brake chamber assy | 10 |
| 14431 | 14431Brake chamber with spring brake actuator type 20/20 assy | 50 |
| 14433 | 14433Auxiliary brake pneumatic cylinder | 31 |
| 14434 | 14434 | 53 |
Which parts fit KAMAZ-53215?
12 part numbers are linked to KAMAZ-53215; open one for its fitment, diagrams and quote.
53205-2506081 / 532052506081 Interaxle differential spider assembly with planet pinions without bushing (repair kit)
53205-2506081 / 532052506081
KAMAZ
53205-2506081-20 / 53205250608120 Interaxle differential spider assembly (repair kit)
53205-2506081-20 / 53205250608120
KAMAZ
How do I find a part for KAMAZ-53215?
Open a system below, pick an assembly diagram, then match the position to its OEM part number.
