Specifications
| Wheel formula | 6x4 |
|---|---|
| Payload, kg | 11350 |
| Engine | КамАЗ-740 |
| Power, hp | 210 |
| Production years | 1980–2007 |
| Type | седельный тягач |
KAMAZ-54112 assembly diagrams
Engine46›
- Чертеж № 86 Trailer hydraulic control valve assemblyRFQ
- Чертеж № 88 Tipping mechanism limiting valve 55102-8614005RFQ
- Чертеж № 94 Engine with equipment assembly, basic configurationRFQ
- Чертеж № 95 Engine with equipment, basic configurationRFQ
- Чертеж № 96 Cylinder block, oil pan and oil filterRFQ
- Чертеж № 97 Flywheel housing installationRFQ
- Чертеж № 98 Valve timing mechanismRFQ
- Чертеж № 99 Crankshaft with flywheel installationRFQ
- Чертеж № 100 Exhaust manifold installationRFQ
- Чертеж № 104 Cylinder blockRFQ
- Чертеж № 105 Cylinder blockRFQ
- Чертеж № 106 Flywheel housingRFQ
- Чертеж № 107 Cylinder headRFQ
- Чертеж № 108 Piston with connecting rod and rings assemblyRFQ
- Чертеж № 109 CrankshaftRFQ
- Чертеж № 110 FlywheelRFQ
- Чертеж № 113 Engine oil coolerRFQ
- Чертеж № 115 Engine crankcase ventilationRFQ
- Чертеж № 124 Installation of solenoid valveRFQ
- Чертеж № 125 Camshaft drive gear, fuel pump drive driven gearRFQ
- Чертеж № 126 Engine fuel systemRFQ
- Чертеж № 127 Intake manifold installationRFQ
- Чертеж № 147 Exhaust muffler installationRFQ
- Чертеж № 148 Engine cooling systemRFQ
- Чертеж № 169 Gearbox with clutch housingRFQ
- Чертеж № 170 Gearbox housing with shaftsRFQ
- Чертеж № 182 Air distributorRFQ
- Чертеж № 183 Splitter engagement valve assyRFQ
- Чертеж № 184 Pressure reducing valveRFQ
- Чертеж № 188 Rear axle housingRFQ
- Чертеж № 192 Intermediate axle housingRFQ
- Чертеж № 203 Rod with pistonRFQ
- Чертеж № 204 Compression valve assyRFQ
- Чертеж № 227 Power steering control valveRFQ
- Чертеж № 238 Single protection valve assyRFQ
- Чертеж № 239 Double protection valve assyRFQ
- Чертеж № 240 Triple protection valve assyRFQ
- Чертеж № 241 Test port valve assyRFQ
- Чертеж № 242 Relay valve assyRFQ
- Чертеж № 246 Palm-type coupling headRFQ
- Чертеж № 247 Trailer brake control valve and control, two-line actuation, assyRFQ
- Чертеж № 248 Trailer brake control valve, single-line actuation, assyRFQ
- Чертеж № 251 Pressure limiting valveRFQ
- Чертеж № 255 Two-way valve assyRFQ
- Чертеж № 270 Electro-pneumatic valveRFQ
- Чертеж № 275 Heater electric motorRFQ
Cooling system14›
- Чертеж № 9 Windshield washer water pumpRFQ
- Чертеж № 149 Radiator and pipelinesRFQ
- Чертеж № 150 Radiator suspensionRFQ
- Чертеж № 153 Installation of radiator sealsRFQ
- Чертеж № 155 Right and left water pipeRFQ
- Чертеж № 156 Water boxRFQ
- Чертеж № 157 Radiator capRFQ
- Чертеж № 158 Water pumpRFQ
- Чертеж № 159 Fan impellerRFQ
- Чертеж № 160 Radiator shutter controlRFQ
- Чертеж № 161 Radiator shuttersRFQ
- Чертеж № 163 Fan drive fluid coupling with front coverRFQ
- Чертеж № 164 Fan drive fluid coupling switchRFQ
- Чертеж № 225 Power steering pipelines and oil coolerRFQ
Fuel system16›
- Чертеж № 102 High-pressure fuel pump installation and driveRFQ
- Чертеж № 118 Pre-start heater fuel pumpRFQ
- Чертеж № 122 Pre-heater fuel tank mountingRFQ
- Чертеж № 128 Fuel tankRFQ
- Чертеж № 129 Fuel pipelinesRFQ
- Чертеж № 130 Coarse fuel filter assemblyRFQ
- Чертеж № 131 Low-pressure fuel pump (ТННД)RFQ
- Чертеж № 138 High-pressure fuel injection pump (ТНВД)RFQ
- Чертеж № 139 High-pressure fuel pumpRFQ
- Чертеж № 141 Fuel injection pump housing assemblyRFQ
- Чертеж № 142 Fuel injection pump housingRFQ
- Чертеж № 143 High-pressure fuel pump sectionRFQ
- Чертеж № 144 InjectorRFQ
- Чертеж № 145 Fine fuel filterRFQ
- Чертеж № 146 Fuel injection advance unitRFQ
- Чертеж № 257 Fuel shut-off pneumatic cylinderRFQ
Transmission18›
- Чертеж № 165 Clutch mechanismRFQ
- Чертеж № 166 Clutch control linkageRFQ
- Чертеж № 167 Clutch control drive booster (PGU)RFQ
- Чертеж № 168 Gearbox with splitter assemblyRFQ
- Чертеж № 171 Gearbox input shaft, models 14 and 15RFQ
- Чертеж № 172 Gearbox shafts and gears, models 14 and 15RFQ
- Чертеж № 186 Drive shaftsRFQ
- Чертеж № 187 Rear axle assemblyRFQ
- Чертеж № 189 Rear axle final driveRFQ
- Чертеж № 190 Rear axle differential and axle shaftsRFQ
- Чертеж № 191 Intermediate axleRFQ
- Чертеж № 193 Intermediate axle final driveRFQ
- Чертеж № 194 Inter-axle differentialRFQ
- Чертеж № 195 Inter-axle differential lock engagement driveRFQ
- Чертеж № 214 Front wheel hubRFQ
- Чертеж № 215 Rear wheel hubRFQ
- Чертеж № 220 Angle gearboxRFQ
- Чертеж № 286 Power take-offRFQ
Suspension & frame17›
- Чертеж № 3 Cab springRFQ
- Чертеж № 26 Mono-tube shock absorber assemblyRFQ
- Чертеж № 79 Tipping mechanism subframe 5511-8601010RFQ
- Чертеж № 80 Tipping mechanism subframe 55102-8601010-20RFQ
- Чертеж № 103 Power unit mountingRFQ
- Чертеж № 137 Governor weight holder, governor weight sleeve, levers with governor correctorsRFQ
- Чертеж № 196 Frame 54112-2800010RFQ
- Чертеж № 199 Installation of front suspension assemblyRFQ
- Чертеж № 200 Front suspensionRFQ
- Чертеж № 201 Front leaf springRFQ
- Чертеж № 202 Front suspension shock absorberRFQ
- Чертеж № 205 Front anti-roll barRFQ
- Чертеж № 206 Rear suspension installation, assemblyRFQ
- Чертеж № 207 Rear leaf springRFQ
- Чертеж № 208 Rear suspension equalizer beamsRFQ
- Чертеж № 209 Rear suspension torque rodRFQ
- Чертеж № 273 Wiring harness installation on vehicle frameRFQ
Brake system17›
- Чертеж № 210 Front axle with brakes assemblyRFQ
- Чертеж № 228 Front wheel brake mechanism, right and leftRFQ
- Чертеж № 229 Rear wheel brake mechanism, right and leftRFQ
- Чертеж № 230 Brake panel and driveRFQ
- Чертеж № 231 Air brake pipelinesRFQ
- Чертеж № 232 Air brake compressorRFQ
- Чертеж № 234 Brake system air line water separatorRFQ
- Чертеж № 235 Air brake pressure regulatorRFQ
- Чертеж № 236 Air brake reservoirsRFQ
- Чертеж № 237 Dual-section brake valveRFQ
- Чертеж № 243 Brake chamber with spring brake actuator type 20/20 assyRFQ
- Чертеж № 244 Brake chamber assy (type 24)RFQ
- Чертеж № 249 Installation of brake force regulatorRFQ
- Чертеж № 250 Brake force regulatorRFQ
- Чертеж № 253 Inverse-acting hand-operated brake valve assemblyRFQ
- Чертеж № 256 Auxiliary brake installation and driveRFQ
- Чертеж № 258 Auxiliary brake pneumatic cylinderRFQ
Steering5›
Electrical system12›
- Чертеж № 13 Instrument panelRFQ
- Чертеж № 259 AlternatorRFQ
- Чертеж № 260 Alternator mounting bracketRFQ
- Чертеж № 261 Storage battery installationRFQ
- Чертеж № 262 StarterRFQ
- Чертеж № 263 Starter and instrument switchRFQ
- Чертеж № 264 Combination light switch assemblyRFQ
- Чертеж № 266 Installation of lighting units on cabRFQ
- Чертеж № 268 Electric hornsRFQ
- Чертеж № 276 Preheater electrical equipmentRFQ
- Чертеж № 277 Instrument and switch panelRFQ
- Чертеж № 279 Oil pressure gauge sensor installationRFQ
Wheels5›
Cab & body63›
- Чертеж № 1 Cab (welded)RFQ
- Чертеж № 2 Bracket and cab balancing mechanism installationRFQ
- Чертеж № 4 Cab rear mounting installation, locking deviceRFQ
- Чертеж № 5 Installation of cab lift limiterRFQ
- Чертеж № 6 Cab base (floor)RFQ
- Чертеж № 8 Windshield wiper and its driveRFQ
- Чертеж № 10 Cab front end assemblyRFQ
- Чертеж № 12 Glove box doorRFQ
- Чертеж № 14 Cab side panel, left and rightRFQ
- Чертеж № 15 Cab rear panelRFQ
- Чертеж № 18 Cab roofRFQ
- Чертеж № 20 Side door assembly, right and leftRFQ
- Чертеж № 21 Door, right (welded)RFQ
- Чертеж № 22 Door, left (welded)RFQ
- Чертеж № 23 Door locks and handlesRFQ
- Чертеж № 24 Driver seatRFQ
- Чертеж № 25 Driver seat position adjustment mechanismRFQ
- Чертеж № 27 Installation of cab heating and ventilation elementsRFQ
- Чертеж № 29 Exterior rear-view mirrorRFQ
- Чертеж № 33 Trim panelRFQ
- Чертеж № 34 Front panel lock, hinge and stop. Fender and mud flap, stepRFQ
- Чертеж № 37 Platform 5320-8500010RFQ
- Чертеж № 38 Platform 53212-8500010RFQ
- Чертеж № 39 Platform 5511-8500020RFQ
- Чертеж № 40 Platform 5511-8500020-01RFQ
- Чертеж № 41 Platform 55102-8500020-10RFQ
- Чертеж № 43 Installation of platform 5511-8500008RFQ
- Чертеж № 44 Platform main boards 5320-8500010RFQ
- Чертеж № 45 Platform main boards 53212-8500010RFQ
- Чертеж № 46 Platform extension boards 55102-8500012RFQ
- Чертеж № 47 Platform additional boards 55102-8500012-10RFQ
- Чертеж № 48 Platform main boards 55102-8500020-10RFQ
- Чертеж № 49 Rear posts and locking mechanism of platform main gates 55102-8500032RFQ
- Чертеж № 50 Platform tailgate latch 55102-8500034RFQ
- Чертеж № 51 Platform tailgate lock installation 5511-8500040RFQ
- Чертеж № 52 Installation of platform stop 55102-8500050RFQ
- Чертеж № 54 Platform extension boards 5320-8500091-02RFQ
- Чертеж № 55 Platform extension boards 53212-8500091RFQ
- Чертеж № 56 Platform base 5320-8501010RFQ
- Чертеж № 57 Platform base 53212-8501010RFQ
- Чертеж № 58 Platform base 55102-8501010-20RFQ
- Чертеж № 59 Platform base frame 55102-8501011-10RFQ
- Чертеж № 60 Platform base frame 5320-8501016RFQ
- Чертеж № 61 Platform base frame 53212-8501016RFQ
- Чертеж № 62 Platform gate latchesRFQ
- Чертеж № 63 Platform boxRFQ
- Чертеж № 66 Platform tent frame installation 5320-8508008RFQ
- Чертеж № 67 Platform tent frame installation 53212-8508008RFQ
- Чертеж № 68 Platform tarpaulin frame 5320-8508008RFQ
- Чертеж № 69 Platform tarpaulin frame 53212-8508008RFQ
- Чертеж № 70 Platform tarpaulin 5320-8508012RFQ
- Чертеж № 71 Installation of platform tarpaulin 53212-8508012RFQ
- Чертеж № 73 Platform tipping stop 5511-8510010RFQ
- Чертеж № 74 Platform tipping stop 5511-8510010-10RFQ
- Чертеж № 75 Platform lifting and tipping device 5511RFQ
- Чертеж № 76 Platform lifting and tipping device 55102RFQ
- Чертеж № 77 Platform lift limiting ropes 55102-8600008RFQ
- Чертеж № 78 Installation of platform supports 55102-8600064-10RFQ
- Чертеж № 81 Tipping mechanism hydraulic cylinder 5511-8603010RFQ
- Чертеж № 82 Tipping mechanism hydraulic cylinder 55102-8603010-10RFQ
- Чертеж № 83 Tipping mechanism hydraulic cylinder installationRFQ
- Чертеж № 84 Tipping mechanism pump 5511-8604000-10RFQ
- Чертеж № 272 Wiring harness installation in vehicle cabRFQ
Other76›
- Чертеж № 7 Floor heat insulation and sealingRFQ
- Чертеж № 11 Glove boxRFQ
- Чертеж № 16 Rear windowRFQ
- Чертеж № 17 Engine compartmentRFQ
- Чертеж № 19 Roof ventilationRFQ
- Чертеж № 28 Drain valveRFQ
- Чертеж № 30 Entry handle, left and rightRFQ
- Чертеж № 31 AshtrayRFQ
- Чертеж № 32 Right and left sun visorRFQ
- Чертеж № 35 Mud flapsRFQ
- Чертеж № 36 Panel lockRFQ
- Чертеж № 42 Installation of tarpaulin 55102-8500004RFQ
- Чертеж № 53 Installation of side board torsion assists 55102-8500054-10RFQ
- Чертеж № 64 Installation of extension board tarpaulin 5320-8508004RFQ
- Чертеж № 65 Installation of extension board tarpaulin 53212-8508004RFQ
- Чертеж № 72 Tarpaulin frame post № 3 latch 5320-8508208RFQ
- Чертеж № 85 Control valve 5511-8607070RFQ
- Чертеж № 87 Oil tank 55102-8608010RFQ
- Чертеж № 89 General view of power unit assemblies and mechanismsRFQ
- Чертеж № 90 Power unit, basic configurationRFQ
- Чертеж № 91 RFQ
- Чертеж № 92 RFQ
- Чертеж № 93 RFQ
- Чертеж № 101 Oil pump installationRFQ
- Чертеж № 111 Oil pumpRFQ
- Чертеж № 112 Coarse oil filterRFQ
- Чертеж № 114 Oil system valveRFQ
- Чертеж № 116 Pre-start heating deviceRFQ
- Чертеж № 117 Pre-heater pump unitRFQ
- Чертеж № 119 Pre-start heater pump unit blowerRFQ
- Чертеж № 120 Pre-heater boilerRFQ
- Чертеж № 121 Pre-heater boiler mountingRFQ
- Чертеж № 123 Centrifugal oil filterRFQ
- Чертеж № 132 Accelerator controlRFQ
- Чертеж № 133 Accelerator linkageRFQ
- Чертеж № 134 Air filter installation on KAMAZ-54112 vehicleRFQ
- Чертеж № 135 Air filterRFQ
- Чертеж № 136 Governor cover, upperRFQ
- Чертеж № 140 Speed governorRFQ
- Чертеж № 151 Expansion tank and pipelinesRFQ
- Чертеж № 152 Drain valveRFQ
- Чертеж № 154 ClampRFQ
- Чертеж № 162 Expansion tankRFQ
- Чертеж № 173 Gearshift mechanismRFQ
- Чертеж № 174 Gearshift mechanism control linkage 14.1703005RFQ
- Чертеж № 175 Gearshift mechanism control linkage 14.1703006RFQ
- Чертеж № 176 Support with gearshift leverRFQ
- Чертеж № 177 Gearshift lever supportRFQ
- Чертеж № 178 Gear splitter with control assemblyRFQ
- Чертеж № 179 Splitter shift mechanism installationRFQ
- Чертеж № 180 Splitter shift mechanismRFQ
- Чертеж № 181 Splitter shift mechanism control linkageRFQ
- Чертеж № 185 Splitter control valveRFQ
- Чертеж № 197 Front bumper and tow hooksRFQ
- Чертеж № 211 Front axle assemblyRFQ
- Чертеж № 223 Pump coverRFQ
- Чертеж № 224 Pump filterRFQ
- Чертеж № 233 Pipe with hoseRFQ
- Чертеж № 245 Isolating valve assemblyRFQ
- Чертеж № 252 Anti-freeze deviceRFQ
- Чертеж № 254 Emergency brake release valve assemblyRFQ
- Чертеж № 265 Lighting systemRFQ
- Чертеж № 267 Rear lamps and reverse lamp installation on vehicle 5410, 54112RFQ
- Чертеж № 269 Air hornsRFQ
- Чертеж № 271 Trailer plug socketRFQ
- Чертеж № 274 Turn signal flasherRFQ
- Чертеж № 278 Speedometer driveRFQ
- Чертеж № 280 Installation of fifth wheel 5410-2700001-01RFQ
- Чертеж № 281 Installation of fifth wheel 54112-2700001RFQ
- Чертеж № 282 Fifth wheel 5410-2702010-01RFQ
- Чертеж № 283 Fifth wheel 54112-2702010RFQ
- Чертеж № 284 Towing deviceRFQ
- Чертеж № 285 Towing hitchRFQ
- Чертеж № 287 Driver's tools and accessoriesRFQ
- Чертеж № 288 Reservoirs, cans, jerrycansRFQ
- Чертеж № 289 RFQ
